Tektronix MDO3024 User Manual

Trigger Setup
Choosing a Trigger Type
To select a trigger:
1. P ush Trigger Menu.
Trigger
Type
Sequence
(B Trigger)
Pulse
Width
Timeout
Runt
Logic
Setup &
Hold
Rise/Fall
Time
Video
2. Push Type tobringuptheTrigger Type
side menu.
NOTE. The bus trigger in the MDO3000
Series w orks on parallel buses even without
an application module. Using the bus trigger
on other buses requires use of a MDO3AERO,
MDO3AUDIO, MDO3AUTO, MDO3FLEX,
MDO3COMP, MDO3EMBD, or MDO3USB
application module.
Bus
3. Turn Multipurpose a to select the desired
trigger type.
4. Complete the trigger setup using the lower
menu controls displayed for the trigger
type. The c ontrols to set up the trigger vary
depending on the trigger type.
Type
Edge
Source
1
Coupling
DC
Slope
Level
100 mV
Mode
Auto
& Holdoff
92 MDO3000 Series Oscilloscopes User Manual

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
