Display Wavefor
morTraceData
5. Push Bandwidth
, and select the desired
bandwidth on the side menu.
The set choices are: Full, 250 MHz, and
20 MHz. Additi
onal choices may appear,
depending on the probe that you use.
Select Full to set the bandwidth to the full
oscilloscop
e bandwidth.
Select 250 MHz to set the bandwidth to
250 MHz.
Select 20 MH
z to set the bandwidth to
20 MHz.
NOTE. 100 MHz and 200 MHz model
oscillosco
pes do not include a 250 MHz option
on the menu.
6. Push Label to create a label for the channel.
(See page 55, Labeling Channels and
Buses.)
7. Push More to access a pop-up menu of
additio
nal features. These are described
below.
Fine Scale
Offset
Position
Probe
Setup
8. Select
Fine Scale to enable Multipurpose
a to make fine vertical scale adjustments.
Desk
ew
9. Select Offset to enable Multipurpose a to
make vertical offset adjustments.
Pus
h Set to 0 V on the side menu to set the
vertical offset to 0 V.
For more information on offset, see Quick
Tip
s. (See page 112, Quic k Tips.)
110 MDO3000 Series Oscilloscopes User Manual

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
