Analyze Wavefor
morTraceData
4. Push the top bu
tton on the side menu to
select the waveform axis for which you want
to show the histogram values: Vertical or
Horizontal.
Off
Vertical
Horizontal
5. Push Source on the side menu and turn
Multipurpos
eato select the channel for
which to display histogram measurements.
Source
(a) 1
6. Push Horiz. Limits on the side menu and
turn the Mul
tipurpose a and Multipurpose
b knobs to set the L (left) and R (right)
boundaries of the histogram box.
Horiz.
Limits
L(a)
-584ns
R(b)
760ns
7. Push Vert. Limits on the side menu and turn
the Multip
urpose a and Multipurpose b to
set the T (top) and B (bottom) boundaries
of the histogram box.
Vert.
Limits
T(a)
-584ns
B(b)
760ns
8. Push -more
-1of2.
-more-
1of2
9. Push Display on the side menu and select
Linear or
Log.
Display
Linear
Log
To Add Measurements on Histogram Data
1. Push Add Measurem ent on the lower menu
to add measurements on the histogram data.
Add Mea-
surement
Remove
Measure-
ment
Indicators DVM
DC
Wave-
form His-
tograms
More
MDO3000 Series Oscilloscopes User Manual 139
