Tektronix MDO3024 User Manual

Installation
3. Push Utility P
age.
Utility
Page
4. Turn Multipurpose a and select I/O.
I/O
5. Push Ether
net & LXI.
Utility
Page
I/O
USB
Computer
Ethernet &
LXI
Network
Configura-
tion
Automatic
Socket
Server
GPIB
1
6. View the top item on the side menu to
determine the condition of the LAN. An
indicat
or turns green for good status and red
if the device detects a fault.
Ethernet
&
LXI LAN
Status
7. Push LAN
Settings to display the network
parameters configured on your oscilloscope.
LAN
Setting
s
8. Push LA
N Reset to restore the LAN defaults
to your oscilloscope.
LAN Reset
9. Push Te
st Connection to check if your
oscilloscope can find an attached network.
Test Con-
nection
10. Push m
ore to see another page of side
menu items.
more 1 of 2
30 MDO3000 Series Oscilloscopes User Manual

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
