Acquire the Sign
al
Event Type
None
Trigger
Acquisi-
tions
(a) 10
5. Push Action
s on the lower menu.
This brings up the Actions side menu. Use
themenutoselectanactiontooccuronthe
event.
Actions
6. Select th
eactiontypefromtheresulting
pop-out menu.
Select
Actions
(a) Stop
Acq
7. Select wh
ether or not to enable the action.
Enable
Action
On Off
8. If you se
lected E-mail Notification from the
list of actions above, you can now select
Configure E-mail from the side menu to
define t
he parameters of the e-mail.
Configure
E-mail
NOTE. There is a single set of SMTP server
settin
gs saved for both Act on Event e-mail
notification and for the e-mail printer ( set through
the Utility > Print Setup > Select Printer > Add
E-mai
lPrintermenus). If you modify the SMTP
settings in one of these two locations, they will
be similarly modified in the other location.
9. Push Repeat. from the lower menu.
This lets you set how many times to repeat
the s
elected event and resulting action.
66 MDO3000 Series Oscilloscopes User Manual
