Tektronix MDO3024 User Manual

Acquire the Sign
al
Standard
CAN 2.0
CAN FD
Bit Rate
500 kbps
FD Bit
Rate
4Mbps
6. Push Standard to select between CAN 2.0
and CAN FD decode/trigger standards.
While CAN FD is
backwards compatible
with CAN 2.0 packets, CAN 2.0 should be
selected for best performance with non CA N
FD bus configu
rations.
FD
Standard
ISO
non-ISO
7. Push Bit R at
e, and turn Multipurp ose a to select from the list of predefined bit rates.
Alternatively, you can set the bit rate to a specific value. To do so, select Custom, and then turn M ultipurpose b to set the
bit rate from 10 kbps to 1 Mbps.
When Stand
ard is s et to CAN FD, this will be the S D bit rate.
8. If Standard is set to CAN FD, push FD Bit Rate, and turn Multipurpose a to select from the list of predefined bit rates.
Alternat
ively, you can set the bit rate to a specific value. To do so, select Custom, and then turn Multipu rpo se b to set
the bit rate from 500 kbps to 7 Mbps for the MDO3000.
9. If Standa
rd is set to CAN FD, push FD Standard to select between ISO (11898-1:2015) and non-ISO (Bosch:2012)
protocol standards.
76 MDO3000 Series Oscilloscopes User Manual

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
