Tektronix MDO4000B Series User Manual

Command Groups
In this case, th
e Digital Collection data returned will be 32-bit packed integers,
where each point is represented as follows. Note that the trigger state bit described
below is only available when ACQuire:MAGnivu is 1 (on).
Table 2-46: Digital Collection: 4 Byte Data
Bit n um ber Description
31– 22 not used
21 trigger state
20
not used (always 1)
19
CH4 digital state
18
CH3 digital state
17
CH2 digital state
16
CH1 digital state
15 D15 state
...
1 D1 state
0 D0 state
8ByteData. When the data width is set to 8 bytes, the Digital Collection
represents
the transition state information for digital channels D0 – D15 and
the digital representations of analog Channels 1 – 4.
The "transition state" refers to MSB and LSB bits which together represent the
state of the digital channel during the sampling period, as fol
lows:
MSB LSB Transition/State
0 0 Low
01High
10
Single transition
1 1 Multiple transitions
If the width specified using the DATa:WIDth command is 8 bytes, the Digital
Collection data returned will be 64-bit packed integers, where each point is
represented as follows:
Table 2-47: Digital Collection: 8 Byte Data
Bit N um ber Description
63 — 52 not used
51
CH4 trans ition state MS B
50
CH3 trans ition state MS B
49
CH2 trans ition state MS B
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-103
