Getting Started
With USB, the sy
stem automatically configures itself. To verify that the USB is
enabled:
1. On the front pa
nel, push Utility.
2. Push Utility Page.
3. Select I/O with the Multipurpose knob.
4. Push USB, and verify that USB is enabled.
5. If USB is disabled, push Connect to Computer on the side menu.
After connection, the host, with appropriate software, can list the oscilloscope as a
USB device with the following parameters: (See Table 1-3.)
Table 1-3: USB Device Parameters
Parameter Value
Manufacturer ID 0x0699 (decimal 1689)
Product ID
The product id varies by model number as
follows:
(You can send the
USBTMC:PRODUCTID:HEXadecimal?
query to read the value)
DPO4104B 0x0405 (decimal 1029)
DPO4054B 0x0406 (decimal 1030)
DPO4034B 0x0407 (decimal 1031)
MSO4104B 0x0409 (decimal 1033)
MSO4054B 0x040A (decimal 1034)
MSO4034B 0x040B (decimal 1035)
MDO4104-6 0x040C (decimal 1036)
MDO4104-3 0x040D (decimal 1037)
MDO4054-6 0x040E (decimal 1038)
MDO4054-3 0x040F (decimal 1039)
DPO4102B 0x0417 (decimal 1047)
DPO4102B-L 0x0418 (decimal 1048)
DPO4104B-L 0x0419 (decimal 1049)
MSO4102B 0x041A (decimal 1050)
MSO4102B-L 0x041B (decimal 1051)
MSO4104B-L 0x041C (decimal 1052)
DPO4014B 0x0426 (decimal 1062)
MSO4014B 0x0428 (decimal 1064)
MDO4014-3 0x042a (decimal 1066)
MDO4034-3 0x042e (decimal 1070)
MDO3000 (all) 0x408 (decimal 1032)
MDO4000C (all) 0x0456 (decimal 1110)
Serial number Serial number
Manufacturer description
“Tektronix”
Interface description “USBTMC-USB488”
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 1-9
