Tektronix MDO4000B Series User Manual

Appendix G: Application Module-enabled Commands
This table lists the commands that become available with installation of an
application module.
Application Module
Commands
Aerospace Serial Triggering and Analysis Module. Enables triggering on packet-level information on
MIL-STD-1553 buses as well as analytical tools such as digital views of the signal, bus views, packet
decoding, search tools, and packet decode tables with time-stamp information.
DPO4AERO,
MDO3AERO
BUS:B<x>:ARINC429A:BITRate
BUS:B<x>:ARINC429A:DATA:FORMAT
BUS:B<x>:ARINC429A:POLarity
BUS:B<x>:ARINC429A:SOUrce
BUS:B<x>:MIL1553B:POLarity
BUS:B<x>:MIL1553B:RESPonsetime:MAXimum
BUS:B<x>:MIL1553B:RESPonsetime:MINimum
BUS:B<x>:MIL1553B:SOUrce
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:Q UALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:ERRTYPE
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:LABel:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:LABel:QUALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:LABel:VA Lue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:SDI
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:SSM
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual G-1
