Commands Listed in Alphabetical Order
Conditions
This command re
quires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SDI <QString>
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SDI?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
Arguments
QString is a quoted string of 2 bits. The allowable characters are 0, 1, and X.
The bits specified in the quoted string replace the least significant bits, leaving
any unspecified upper bits unchanged.
NOTE. The SDI field is only present when the selected data field format is DATA
(using BUS:B<x>:ARINC429A:DATA:FORMAT). Also, the stored QString is
reset to its default value whenever the data field format is changed.
Examples
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SDI "X0" sets the
SDI field value to X0.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SDI? might return
"XX".
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:SSM
This command specifies the value for the SSM field to be used when searching
on the ARINC429 bus
data field(s). The search condition must be set to DATA
or LABELANDDATA (using SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:
ARINC429A:CONDition). The default is all X's (don't care). SEARCH<x> is the
search number, which is always 1. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SSM <QString>
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SSM?
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-619
