Tektronix MDO4000B Series User Manual

Command Groups
Table 2-18: Bus
Commands
Commands Description
BUS? Returns the parameters for each seria l (if installed) and parallel bus.
BUS:B<x>:ARINC429A:BITRate This command specifies the bit rate for the ARINC429 bus.
BUS:B<x>:ARINC429A:DATA:
FORMAT
This command specifies the size of the DATA field in an ARINC429 packet.
BUS:B<x>:ARINC429A:POLarity This command sets the ARINC429 bus polarity to normal or inverted.
BUS:B<x>:ARINC429A:SOUrce This command specifies the source for differential input for the ARINC429 bus.
BUS:B<x>:AUD io:BITDelay This command specifies the number of delay bits for the AUDIO bus
BUS:B<x>:AUDio:BITOrder This command specifies the bit order for the AUDIO bus
BUS:B<x>:AUD io:C H A N nel:SIZe This command specifies the number of bits per channel for the AUDIO bus
BUS:B<x>:AUDio:C LOCk:POLarity This command specifies the clock polarity for the AUDIO bus
BUS:B<x>:AUD io:C LOC k:SOUrce This command specifies the clock source waveform for the AUDIO bus
BUS:B<x>:AUDio:DATa:POLarity This command specifies the data polarity for the AUDIO bus
BUS:B<x>:AUDio:DATa:SIZe This command specifies the number of bits per word for the AUDIO bus
BUS:B<x>:AUDio:DATa:SOUrce This command specifies the data source waveform for the AUDIO bus
BUS:B<x>:AUDio:DISplay:FORMat This command specifies the display format for the AUDIO bus
BUS:B<x>:AUD io:F RAME:SIZe This command specifies the number of channels in each frame for the AUDIO bus
BUS:B<x>:AUDio:FRAMESync:
PO
Larity
This command specifies the frame sync polarity for the A UDIO bus
BU
S:B<x>:AUDio:FRAMESync:
SOUrce
Th
is command specifies the frame sync source waveform for the AUDIO bus
BUS:B<x>:AUDio:TYPe This command specifies the audio format (type) for the AUDIO bus
BUS:B<x>:AUDio:WORDSel:
POLarity
This command specifies the word select polarity for the AUDIO bus
BUS:B<x>:AUDio:W ORDSel:SOUrce This command specifies the word select source waveform for the AUDIO bus
BUS:B<x>:CAN:FD:BITRate This command specifies the bit rate for the data phase of a CAN FD packet
BUS:B<x>:CAN:FD:STANDard This command specifies the CAN FD standard: ISO (11898-1:2015) or non-ISO
(Bosch:2012)
BUS:B<x>:CAN:BIT Rate This command specifies the bit rate for the CA N bus
BUS:B<x>:CAN:PRObe This command specifi es the probing method for the CAN bus
BUS:B<x>:CAN:SAMPLEpoint This command specifies the sample point (in %) to sample during each bit period
BUS:B<x>:CAN:STANDard This command specifies CAN or CAN FD bust standard: CAN 2.0 or CAN FD
BUS:B<x>:CAN:SOUrce This command specifies the CAN bus data source
BUS:B<x>:DISplay:FORMat Sets the display format for the numerical information in the specified bus waveform
BUS:B<x>:DISplay:TYPe Sets the display type for the specified bus
BUS:B<x>:ETHERnet:PRObe This command specifies the Ethernet probe type: differential or single-ended.
BUS:B<x>:ETHERnet:PROTOcol Use this command to set the Ethernet protocol type to TCP/IPv4, or to OTHER.
BUS:B<x>:ETHERnet:SOUrce:
DIFFerential
This command specifies the Ethernet data source for differential input.
2-16 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
