Commands Listed in Alphabetical Order
Arguments
CURsor — curren
tly this is the only button supported by this command. If the
hold time is not specified, it defaults to 1200 milliseconds. The range is 0 to
10,000 milliseconds. The system expects a minimum of 1 second to recognize a
hold.
<NR1> (optional), an integer, is the hold time — ie. the time to emulate holding
the button down before releasing it, in milliseconds. If the hold time is not
specified, it defaults to 1200 milliseconds.
Examples
FPAnel:HOLD CURsor — This simulates pressing and holding the CURSOR
button for 1200 milliseconds.
FPAnel:PRESS (No Query Form)
Simulates the action of pressing a specified front-panel button.
When the front panel is locked, the front-panel button and multipurpose
knob operations are suspended. The
FPAnel:PRESS and the FPAnel:TURN
commands will also not work. You can work around this by using the appropriate
programmatic interface commands, instead of the front-panel commands.
Group
Miscellaneous
Syntax
FPAnel:PRESS <button>
Arguments
<button> is the name of a front-panel button. Most of the argument names
associate directly with their front panel buttons. For example, AUTOSet isfor
the Autoset button.
Table 2-54: FPAnel:PRESS arguments
Argument Description
ACQuire
Acquire button
AFG Arbitrary Function Generator button
AUTOset
Autoset button
BMENU<x>
Screen bottom menu buttons, where <x>=1
for the left-most bottom menu button and
<x>=7 for the right-most bottom menu button
B<x> Bus select buttons, where <x> = 1–4 or 1–2
depending on the model
CH<x> Channel select button, where <x>=1 for
channel 1, <x>=2 for channel 2, and so on
CURsor Cursors button
2-328 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
