Commands Listed in Alphabetical Order
FPAnel:TURN (
No Query Form)
Simulates the action of turning a specified front-panel control knob.
When the front panel is locked, the front-panel button and multipurpose knob
operations are suspended. The FPAnel:PRESS and
FPAnel:TURN commands
will also not work, and, they will not generate an error. You can work around
this by usin
g the appropriate programmatic interface commands, instead of the
front-panel commands. For example, to set the trigger level to 50%, you could
use TRIGger:A SETLevel. To force a trigger, you could use TRIGger FORCe.
Group
Miscellaneous
Syntax
FPAnel:TURN <knob>,<n>
Arguments
<knob> is the name of a rotating control.
A comma (,) separates the control knob argument from the numeric rotation value
argument. You do not need a white space between the arguments and the comma.
<n> represents the rotation direction and magnitude of rotation. Negative values
represent a counterclockwise knob rotation, and positive values represent a
clockwise rotation. The magnitude of <n> specifies the amount of the turn, where
<n> = 1 represents turning the knob one unit, <n> = 2 represents turning the knob
two units, <n> = 4 represents turning the knob four units, and so on. The rangeof
units depends on which front panel knob is specified.
Table 2-55: FPAnel:TURN arguments
Argument Description
GPKNOB1
Multipurpose a knob
GPKNOB2
Multipurpose b knob
HORZPOS
Horizontal Position knob
HORZScale Horizontal Scale knob
PANKNOB1 Outer pan knob
TRIGLevel
Trigger Level knob
VERTPOS<n>
Vertical Position knob
VERTSCALE<n> Vertical Scale knob
ZOOM
Inner zoom knob
Examples
FPANEL:TURN TRIGLEVEL,10 duplicates turning the front-panel Trigger Level
knob clockwise by 10 units.
2-330 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
