Commands Listed in Alphabetical Order
D0-D15 specifie
s a digital channel as the data source waveform for the audio bus.
(MSO/MDO4000/B models only as well as MDO3000 and MDO4000C models
with option MDO3MSO or MDO4MSO installed.)
Examples
BUS:B1:AUDIO:DATA:SOURCE D1 sets the data source to D1.
BUS:B1:AUDIO:DATA:SOURCE? might return :BUS:B1:AUDIO:DATA:SOURCE
CH3
indicating that the data source is set to CH3.
BUS:B<x>:AUDio:DISplay:FORMat
Specifies the display format for the AUDIO bus.
Conditions
This command requires the DPO4AUDIO application module for the
MDO4000/B/C series, or the MDO3AUDIO for MDO3000 series.
Group
Bus
Syntax
BUS:B<x>:AUDio:DISplay:FORMat
{BINary|HEXadecimal|SIGNEDDECimal}
BUS:B<x>:AUDio:DISplay:FORMat?
Arguments
BINary specifies a binary data display.
HEXadecimal specifies a hexadecimal data display.
SIGNEDDECimal specifies a signed decimal data display.
Examples
BUS:B1:AUDIO:DISPLAY:FORMat BINARY sets the display format to Binary.
BUS:B1:AUDIO:DISPLAY:FORMat? might return
:BUS:B1:AUDIO:DISPLAY:FORMAT SIGNEDDECIMAL indicating that the
display format is set to signed decimal.
BUS:B<x>:AUDio:FRAME:SIZe
Specifies the number of channels in each frame for the AUDIO bus.
NOTE. This command is applicable only for TDM audio bus type
(
BUS:B<x>AUDio :TYPe TDM
)
2-164 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
