Command Groups
Table 2-18: Bus Commands (cont.)
Commands Description
BUS:B<x>:ETHERnet:SOUrce:
DMINus
This command specifies the Ethernet data source for D- input for single-ended probing.
BUS:B<x>:ETHERnet:SOUrce:
DPLUs
This command specifies the Ethernet data source for the D+ input for single-ended probing.
BUS:B<x>:ETHERnet:TYPe This command specifies the Ethernet standard type: 10B ase-T or 100Base-T.
BUS:B<x>:FLEXray:BITRate This command specifies the bit rate for the FlexRay bus signal
BUS:B<x>:FLEXray:CHannel This command specifies the FlexRay bus ID format
BUS:B<x>:FLEXray:SIGnal This command specifies the FlexRay bus standard
BUS:B<x>:FLEXray:SOUrce This command specifies the F lexRay bus data source
BUS:B<x>:I2C:ADDRess:RWINClude Sets and returns whether the read/write bit is included in the address
BUS:B<x>:I2C{:CLOCk|:SCLk}:
SOUrce
This command specifies the I2C bus SCLK source
BUS:B<x>:I2C{:DATa|:SDAta}:
SOUrce
This command specifies the I2C bus SDATA source
BUS:B<x>:LABel This command specifies the waveform label for the specified bus
BUS:B<x>:LIN:BITRate This command specifies the bit rate for the LIN bus.
BUS:B<x>:LIN:IDFORmat This command specifies the LIN bus ID format
BUS:B<x>:LIN:POLarity This command specifies the LIN bus polarity
BUS:B<x>:LIN:SAMPLEpoint This command specifies the point to sample during each bit period, as a percent, for the
LIN bus.
BUS:B<x>:LIN:SOUrce This command specifies the LIN bus data source
BUS:B<x>:LIN:STANDard This command specifies the LIN bus standard
BUS:B<x>:MIL1553B:POLarity This command sets the MIL-STD-1553 bus polarity to normal or inverted.
BUS:B<x>:MIL1553B:
RESPonsetime:MAXimum
This command specifies the m aximum response time to a valid command issued for the
MIL-STD-1553 bus.
BUS:B<x>:MIL1553B:
RESPonsetime:MINimum
This command specifies the minimum response time to a valid command issued for the
MIL-STD-1553 bus.
BUS:B<x>:MIL1553B:SOUrce This command specifies the source for differential input for the MIL-STD-1553 bus.
BUS:B<x>:PARallel:BIT<x>:SOUrce This command specifies the bit source for the parallel bus.
BUS:B<x>:PARallel:CLOCk:EDGE This command specifies the clock edge for the parallel bus
BUS:B<x>:PARallel:CLOCk:
ISCLOCKed
This command specifies the state of the clock function for the parallel bus.
BUS:B<x>:PARallel:CLOCk:SOUrce This command specifies the clock source waveform for the parallel bus.
BUS:B<x>:PARallel:WIDth This command specifies the number of bits to use for the width of the parallel bus.
BUS:B<x>:POSition This command specifies the position of the bus waveform on the display.
BUS:B<x>:RS232C:BITRate This command specifies the bit rate for the RS-232 bus.
BUS:B<x>:RS232C:DATABits This command specifies the number of bits in the data frame for the RS-232 bus.
BUS:B<x>:RS232C:DELIMiter This command specifies the delimiting value for a packet on the RS-232 bus.
BUS:B<x>:RS232C:DISplaymode This command specifies the display mode for the RS-232 bus (frame or packet).
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-17
