Commands Listed in Alphabetical Order
Syntax
BUS:B<x>:CAN:
SAMPLEpoint <NR1>
BUS:B<x>:CAN:SAMPLEpoint?
Arguments
<NR1> is the sample point in percent. Values can be any integer from 5 to 95.
For a CAN 2.0 bus the allowable sample point range is 5% to 95%.
For a CAN FD bus the allowable sample point range is 15% to 95%.
NOTE. CAN FD requires an accurately specified sample point for correct decode
and triggering.
NOTE. CAN FD uses the same sample point percentage for bits transmitted at SD
bit rates and FD bit rates. For optimal performance, set the sample point to the
value used for SD bits (the "Arbitration Phase" sample point).
BUS:B<x>:CAN:SOUrce
Specifies the CAN bus data source.
Conditions
This command requires a DPO4AUTO or DPO4AUTOMAX application
module for all 4000 series models, and the MDO3AUTO application module
for MDO3000 series models.
Group
Bus
Syntax
BUS:B<x>:CAN:SOUrce {CH1|CH2|CH3|CH4|
D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11| D12|D13|D14|D15}
BUS:B<x>:CAN:SOUrce?
Arguments
CH1–CH4 specifies an analog channel as the data source waveform.
D0–D15 specifies a digital channel as the data source waveform.
(MSO/MDO4000/B models only as well as MDO3000 and MDO400C models
with option MDO3MSO or MDO4MSO instal
led.)
BUS:B<x>:CAN:STANDard
Specifies the CAN bus standard to use.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-171
