Commands Listed in Alphabetical Order
Related Commands
BUS:B<x>:ARIN
C429A:DATA:FORMAT
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
Arguments
QString is a quoted string of 2 bits. The allowable characters are 0, 1, and X.
The bits specified in the quoted string replace the least significant bits, leaving
any unspecified upper bits unchanged.
NOTE. The SSM field is only present when the selected data field format is DATA
or SDIDATA (using BUS:B<x>:ARINC429A:DATA:FORMAT). Also, the stored
QString is reset to its default value whenever the data fi eld format is changed.
Examples
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:SSM "X0" sets the
SSM field value to X0.
SEARCH:SEARCH<x>>:TRIGger:A:BUS:B<x>:A RINC429A:SSM? might return
"XX".
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:CONDition
This command sets the condition (start of frame or matching data) to be used to
search on audio bus data.
SEARCH<x> is the search number, which is always 1, and
B<x> is the bus number (1-4). 1-3 for the MDO4000C and 1-2 for the MDO3000.
Conditions
This command requires a DPO4AUDIO application module on DPO/MSO4000B
and MDO4000/B/C models and a MDO3AUDIO application module on
MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AU Dio:CONDition
{SOF|DATA}
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AU Dio:CONDition?
Arguments
SOF specifies to search on the start of frame.
DATA specifies to search on matching data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:HIVALue
This command sets the upper word value to be used to search on audio bus data.
(Use SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:VALue to
2-620 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
