Commands Listed in Alphabetical Order
DATA specifies a
search for matching packet data field(s).
LABELANDDATA specifies a search for matching label and matching packet data
field(s).
ERROR specifies a search for specified packet error.
NOTE. The ty
pe of error searched for is specified by SEARCH:SEARCH<x>:
TRIGger:A:BUS:B<x>:ARINC429A:ERRTYPE
Examples
SEARCH:SEARCH1:TRIGger:A:BUS:B1:ARINC4 29A:CONDITION STARt sets
the search condition to find the first bit of a word.
SEARCH:SEARCH1:TRIGger:A:BUS:B1:ARINC4 29A:CONDITION? might
return ERROR, indicating the ARINC429 search condition is for packet errors.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
When the search condition is set to DATA or LABELANDDATA, and the
qualifier is set to either INrange or OUTrange, this command specifies the
upper value of the range for a match on the data field. (Use the command
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
to specify the lower value of the range). The default is all X’s (don’t care).
SEARCH<x> is the search number, which is always 1. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO applicati
on module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:HIVALue
<QString>
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:HIVALue?
Related Commands
BUS:B<x>:ARI
NC429A:DATA:FORMAT
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
SEARCH:SEAR
CH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
2-612 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
