Commands Listed in Alphabetical Order
EQual sets the d
ata qualifier to equal.
UNEQual sets the data qualifier to not equal.
LESSEQual sets the data qualifier to less than or equal.
MOREEQual sets the data qualifier to greater than or equal.
INrange sets the data qualifier to in range.
OUTrange sets the data qualifier to out of range.
NOTE. The search qualifier only applies to the bits defined as the data field via the
bus data field format specifier (using BUS:B<x>:ARINC429A:DATA:FORMAT).
Examples
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:QUALifier
LESSthan
sets the label qualifier to less than.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>>:A RINC429A:DATA:QUALifier?
might return EQUAL indicating the label qualifier is set to =.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
This command specifies the low value to be used when searching on the
ARINC429 bus data field(s). The search condition must be set to DATA or
LABELANDDATA (using SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:
ARINC429A:CONDition). The default is all X's (don't care). SEARCH<x> is the
search number, which is always 1. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:VALue
<QString>
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:VALue?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUALifier
2-614 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
