Commands Listed in Alphabetical Order
Arguments
<NR3> is a floati
ng point number that specifies the low reference level, in volts.
The default is 0.0 V.
Examples
MEASUREMENT:REFLEVEL:ABSOLUTE:LOW 0.0 sets the low reference level
to 0.0 V.
MEASUREMENT:REFLEVEL:ABSOLUTE:LOW? might return
:MEASUREMENT:REFLEVEL:ABSOLUTE:LOW 0.0000E+00 indicating
that the absolute low reference level is set to 0.0 V.
MEASUrement:REFLevel:ABSolute:MID<x>
This command specifies an absolute mid reference level (the 50% reference level)
for the "to" waveform when taking a delay measurement, in volts. There are
two absolute mid reference levels; thus MID<x> can either be MID1 or MID2.
This command applies when MEASUrement:REFLevel:METHod has been set
to Absolute. This command is equivalent to setting the Reference Levels in the
MEASURE menu on the oscilloscope front panel.
NOTE. This command affects the results of period, frequency, delay, and all cyclic
measurements. This command affects the associated reference level parameter for
all MEASurements:IMMed and the four periodic measurements.
Group
Measurement
Syntax
MEASUrement:REFLevel:ABSolute:MID<x> <NR3>
MEASUrement:REFLevel:ABSolute:MID<x>?
Related Commands
MEASUrement:REFLevel:METHod
Arguments
<NR3> is a floating point number that specifies the mid reference level in volts.
Examples
MEASUrement:REFLevel:ABSolute:MID 0.5 sets the absolute MID1
reference level for the delay waveform to 0.5 V.
MEASUrement:REFLevel:ABSolute:MID? might return
:MEASUREMENT:REFLEVEL:ABSOLUTE:MID2 0.5000E+00 indicating that the
absolute MID2 reference level is set to 0.5 V.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-447
