Commands Listed in Alphabetical Order
SEARCH:SEARC
H<x>:LIST? (Query Only)
This query returns a list of all automatically created search marks on waveforms
in the time domain (leaving out any manually created marks). These automatic
marks are cre
ated using a search command. The entries returned are in the form
of an enumeration representing the source waveform, followed by 7 time mark
parameters.
SEARCH<x> is the search number, which is always 1. To return a list
of manual marks, use the query form of MARK:USERLIST.
NOTE. A series of example command sequences showing different searches and
triggers is included as an appendix. (See page F-1, Search and Trigger Command
Sequence
Examples.)
Group
Search
Syntax
SEARCH:SEARCH<x>:LIST?
Related Commands
MARK:USERLIST, MARK:SAVEALL
Returns
The query is returned in the form: (
<Enum>,<NR3>,<NR3>,<NR3>,<NR3>,<NR3>,<NR3>,<NR3>) ..
<Enum> is the source waveform.
The 7 NR3 time mark parameters returned are as follows:
Start — start value in percent of record
End — end value in percent of record
Focus — focus value in percent of record
X value — horizontal value of the focus point in the mark’s waveform units
Y value — vertical value of the focus point in the mark’s waveform units
Delta X value — always 0, since there is no time-domain reference mark.
Delta Y value — always 0, since there is no time-domain reference mark.
Examples
SEARCH:SEARCH1:LIST? might return
CH1,23.6824,23.6824,23.6824,-1.0527E-3,-26.7798,0.0E+0,0.0E+0;CH1,50.0050,
50.0050,50.0050,200.0200E-9,-25.4704,0.0E+0,0.0E+0;CH1,
76.3376,76.3376,76.3376,1.0535E-3,0.0E+0,0.0E+0,0.0E+0 which
indicates three search marks on Channel 1.
2-608 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
