Commands Listed in Alphabetical Order
OFF sets the val
ue to 0.
ON sets the value to 1.
Examples
SEARCH:SEARCH1:TRIGger:A:BUS:B1:MIL155 3B:COMMAND:PARity ZERo
sets the Command word parity bit to 0.
SEARCH:SEARCH1:TRIGger:A:BUS:B1:MIL155 3B:COMMAND:PARity?
might return 0, 1 or X.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:SUBADdress
When the MIL-STD-1553 bus search condition is set to COMMAND, this command
specifies the 5 bit sub-address that is to be used in the search. When the
sub-address value is set to 00000 or 11111 binary, it specifies that the command is
a “Mode Code” command. Any other value specifies that it is a “Word Count”
command. The default is all X’s (don’t care).
SEARCH<x> is the search number,
whichisalways1,and
B<x>
NOTE. The sub-address field is used to direct data to different functions within the
subsystem for values 1 — 30.
Conditions
This command requires a DPO4AERO application module for DPO/MSO4000B
and MDO4000/B/C models or MDO3AERO application module for
MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MI L1553B:COMMAND:
SUBADdress <QString>
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MI L1553B:COMMAND:
SUBADdress?
Related Commands
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:CONDition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:
COUNt
Arguments
QString is a quoted string of up to 5 characters, where the allowable characters are
0, 1, and X.
2-676 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
