Commands Listed in Alphabetical Order
TRIGger:A:BUS
:B<x>:ARINC429A:DATA:HIVALue?
might return
"XXXXXXXXXXXXXXXXXXX".
TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUALifier
This command specifies the qualifier to be used when triggering on the ARINC429
data field(s). The trigger condition must be set to DATA or LABELANDDATA.
The default qualifier is “Equal to”. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUAL ifier
{LESSthan|MOREthan|Equal|UNEQual|LESSE Qual|MOREEQual|
INrange|OUTrange}
TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUAL ifier?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
Arguments
LESSthan sets data qualifier to less than.
MOREthan sets the data qualifier to greater than.
EQual sets the data qualifier to equal.
UNEQual sets the data qualifier to not equal.
LESSEQual sets the data qualifier to less than or equal.
MOREEQual sets the data qualifier to greater than or equal.
INrange sets the data qualifier to in range.
OUTrange sets the data qualifier to out of range.
NOTE. Thetriggerqualifier only applies to the bits defined as the data field via the
bus data field format specifier (using BUS:B<x>:ARINC429A:DATA:FORMAT)
2-776 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
