Commands Listed in Alphabetical Order
Examples
TRIGger:A:BUS
:B<x>:ARINC429A:LABel:VALue
"XXXX1000" sets the
upper limit of the range to XXXX1000.
TRIGger:A:BU
S:B<x>:ARINC429A:LABel:VALue?
might return
"XXXXXXXX".
TRIGger:A:BUS:B<x>:ARINC429A:SDI
This command specifies the value for the SDI field to be used when triggering on
the ARINC429 bus data field(s). The trigger condition must be set to DATA or
LABELANDDATA (using TRIGger:A:BUS:B<x>:ARINC429A:CONDition).
The defau
lt is all X's (don't care). B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ARINC429A:SDI <QString>
TRIGger:A:BUS:B<x>:ARINC429A:SDI?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
Arguments
QString is a quoted string of 2 bits. The allowable characters are 0, 1, and X.
The bits specified in the quoted string replace the least significant bits, leaving
any unspecified upper bits unchanged.
NOTE. The SDI field is only present when the selected data field format is DATA
(using BUS:B<x>:ARINC429A:DATA:FORMAT). Also, the stored QString is
reset to its default value whenever the data field format is changed.
Examples
TRIGger:A:BUS:B<x>:ARINC429A:SDI "X0" sets the SDI field value to X0.
TRIGger:A:BUS:B<x>:ARINC429A:SDI? might return "XX".
TRIGger:A:BUS:B<x>:ARINC429A:SSM
This command specifies the value for the SSM field to be used when triggering on
the ARINC429 bus data field(s). The trigger condition must be set to DATA or
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-781
