Tektronix MDO4000B Series User Manual

Commands Listed in Alphabetical Order
Examples
TRIGGER:B:LEV
EL TTL
sets the B trigger level to 1.4 V.
TRIGGER:B:LEVEL? might return :TRIGGER:B:LEVEL 173.0000E-03
indicating that the B trigger level is currently set at 173 mV.
TRIGger:B:LEVel:CH<x>
This command specifies the B trigger level for channel <x>, where x is the
channel number. Each Channel can have an independent Level.
Group
Trigger
Syntax
TRIGger:B:LEVel:CH<x> {ECL|TTL|<NR3>}
TRIGger:B:LEVel:CH<
x>?
Arguments
ECL specifies a preset ECL high level of –1.3V.
TTL specifies a preset TTL high level of 1.4V.
<NR3> is a floating point number that specifies the trigger level in user units
(usually volts).
Examples
TRIGGER:B:LEVEL:CH2? might return :TRIGGER:B:LEVE L:CH2
1.3000E+00
indicating that the B edge trigger is set to 1.3 V for channel 2.
TRIGGER:B:LEVEL:CH3 TTL sets the B edge trigger to TTL high level for
channel 3.
TRIGger:B:LEVel:D<x>
This command specifies the B trigger level for digital channel <x>, where x isthe
channel number. Each chann
el can have an independent level.
NOTE. MDO3000 models only have two digital threshold controls: one for digital
channels D0 - D7, and the o ther for D8 - D15. Digital channel trigger levels
cannot be set independently for these models. Changing one digital channel’s
threshold l evel changes all of the channels’ levels in the same set.
Group
Trigger
Syntax
TRIGger:B:LEVel:D<x> {ECL|TTL|<NR3>}
TRIGger:B:LEVel:D<x>?
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-925

Tektronix MDO4000B Series Specifications

General

Bandwidth	100 MHz to 1 GHz
Form Factor	Benchtop
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Timebase Accuracy	± 1 ppm
Operating Temperature	0 °C to +50 °C
Built-in Spectrum Analyzer	Yes
Channels	up to 4 analog channels
Record Length	up to 20 Mpoints
Display	10.4 inch (264 mm) color TFT LCD
Connectivity	USB, LAN, GPIB (optional)
RF Capture Bandwidth	Up to 1 GHz
Arbitrary/Function Generator	optional
Input Impedance	1 MΩ || 13 pF
Trigger Types	Edge, Pulse Width
Protocol Analysis	I2C, SPI, CAN, LIN, RS-232/422/485/UART, USB 2.0, Ethernet, FlexRay, MIL-STD-1553
