Tektronix MDO4000B Series User Manual

Commands Listed in Alphabetical Order
WFMInpre:BN_Fmt
This command specifies the format of the data for outgoing waveforms when
WFMInpre:ENCdg is set to BI Nary . The format can either be RI (signed integer),
RP (positive integer) or FP (floating point).
(See page 2-95, Waveform Transfer Command Group.)
Group
Waveform Transfer
Syntax
WFMInpre:BN_Fmt {RI|RP|FP}
WFMInpre:BN_Fmt?
Related Commands
WFMOutpre:BN_Fm
t
WFMInpre:ENCdg
Arguments
RI specifies signed integer data point representation.
RP specifies positive integer data point representation.
FP specifies floating point data representation.
Examples
WFMINPRE:B
N_FMT RP
specifies positive integer data point representation.
WFMINPRE:BN_FMT? might return :W FMINPRE:BN_FMT RI indicating that the
incoming d
ata is currently interpreted as signed integers.
WFMInpre:BYT_Nr
This command specifies the number of bytes per data point in the waveform data
to be sent to the oscilloscope using the
CURVe command. Changing this value also
changes the value of WFMInpre:BIT_Nr.
(See page 2-95, Waveform Transfer Command Group.)
NOTE. The
WFMInpre:BYT _Nr and WFMInpre:BI T_Nr settings are directly
related; setting one causes the other to be set accordingly. For example,
WFMIn
pre:BYT_Nr 2
causes WFMInpre_B IT_Nr tobesetto16(2*8bits/byte).
Similarly, setting
WFMInpre:BIT _Nr to 16 causes WFMInpre:B YT_Nr to be
set to 2.
Group
Waveform Transfer
2-946 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
