Specifications
Ta ble 4: Trigger specifications (cont.)
Source
Range
Any input channel
±8 divisions from center of screen
±8 divisions from 0 V when vertical LF reject
trigger coupling is selected
Line Not applicable
Trigger level ranges
Line trigger level is fi xed at about 50% of the line voltage.
This specification applies to logic and pulse thresholds.
For signals having rise and fall times 10 ns.
Source
Range
Any input channel ±0.20 div
Trigger level accuracy, D C coupled,
typical
Line Not applicable
Trigger holdoff range
20 ns minimum to 8 s maximum
Maximum serial trigger bits 128 bits
Standard serial bus interface triggering
I
2
C Address Triggering: 7 and 10 bit user specified addresses, as well as General Call, START
byte, H S-mode, EEPROM, and CBUS
Data Trigger: 1 to 5 b ytes of user specified data
Trigger On: Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and Data
Maximum Data Rate: 10 Mbps
SPI Data Trigger: 1 to 16 bytes of user-specified data
Trigger On: SS Active, MOSI, MISO, or MO SI & MISO
Maximum Data Rate: 50 Mbps
CAN Data Trigger: 1 to 8 bytes of user-specified data, including qualifiers of equal to (=), not equal
to (<>), less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=)
Trigger On: Start of Frame, Type of Frame, Identifier, Data, Identifier and Data, End of
Frame, Missing Ack, or Bit Stuffing Errors
Frame Type: Data, Remote, Error, Overload
Identifier: Standard (11 bit) and Extended (29 bit) identi fiers
Maximum Data Rate: 1 Mbps
LIN
Identifier Trigger: 6 b its of user-specified data, equal to (=)
Data Trigger: 1 to 8 bytes of user-specified data, including qualifiers of equal to (=), not
equal to (<>), less than (<), greater than (>), less than or equal to (<=), greater than or
equal to (>=), inside range, or outside range
Error: Sync, Identifier Parity, Checksum
Trigger On: Sync, Identifier, Data, Identifier & Data, Wakeup Frame, Sleep Frame, or Error
Maximum Data Rate: 100 kbps
MDO4000 Series Specifications and Performance Verification 13
