Specifications
Table 4: Trigger specifications (cont.)
FlexRay
Indicator bits: Normal F rame, Payload Frame, Null Frame, Sync Frame, Startup Frame
Identifier Trigger: 11 bits of user-specified data, equal to (=), not equal to (<>), less than (<),
greater than (>), less than or equal to (<=), greater than or equal to (>=), Inside Range, or
Outside Range
Cycle Count Trigger: 6 bits of user-specified data, equal to (=)
Header Fields Trigger: 40 bits of user-specified data comprising Indicator Bits, Identifier,
Payload Length, Header CRC, Cycle Count, or equal to (=)
Data Trigger: 1 to 16 Bytes of user-specified data, with 0 to 253, or "don't care" bytes of data
offset, including qualifiers of equal to (=), not equal to <>, less than (<), greater than (>), less
than or equal to (<=), greater than or equal to (>=), Inside Range, Outside Range
End Of Frame: User-chosen types Static, Dynamic (DTS), and All
Error: Header CRC, Trailer CRC, Null Frame-static, Null Frame-dynamic, Sync Frame,
Startup Frame
Trigger On: Start of Frame, Indicator Bits, Identi fier, C ycle Count, Header Fields, D ata,
Identifier & Data, End of Frame, or Error
Maximum Data Rate: 100 Mbps
Audio
I
2
S Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
Left Justifi ed Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
Right Justified Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
TDM
Data Trigger: 32 bits of user-specified data in a c hannel 0-7, including qualifiers of equal to
(=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or
equal to (>=), inside range, outside range
Trigger on: Frame Sync, Data
Maximum Data Rate: 25 Mbps
RS-232
Bit R ate: 50 bps to 10 Mbps
Data Bits: 7, 8, or 9
Parity: None, Odd, or Even
Trigger on: Tx Start bit, Rx Start bit, Tx End of Packet, Rx End of Packet, Tx Data, Rx
Data, Tx Parity Error, Rx Parity Error
End of Packet: 00(NUL),OA(LF),OD(CR),20(SP),FF
14 MDO4000 Series Specifications and Performance Verification
