Controls Description

Use the eSATA port as an external interface for SATA support

devices.

NOTE. This port is available only on MSO70000C/DX,

DPO70000C/DX, and DPO7000C Series instruments.

For DPO70000SX instruments:

Use the Display Port to connect to a monitor.

Use the PCIe ports to connect to a PC or to set up a multi-

instrument configuration.

Use the Trigger ports to set up a multi-instrument configuration.

Use the 12.5 GH Clock In and Out to set up a multi-instrument

configuration.

Controls and connectors

84 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
