Pinpoint trigge
rs
Trigger Type Trigger Condit
ions
Comm Trigger with m
ask testing on communications codes and standards (analog channels
only). The controls work together to define the parameters for the trigger event
(availablewithOptionMTMorMTHonsomeinstruments). This mode includes clock
recovery. Pus
h the Push to Set 50% knob to reinitialize clock recovery.
Bus
Trigger on co
mponents (such as a specified address) of a bus that you define.
With some instruments and options, trigger types include parallel, SPI, RS-232,
USB, and I
2
C triggers.
Not recomme
nded with iCapture inputs if using more than one source or an external
trigger.
Video
Trigger on specified fields or lines of a composite v ideo signal (DPO7000C,
MSO5000, and DPO5000 Series only). Only composite signal formats are supported.
CAN Trigger on CAN Bus signals.
Not recom
mended with iCapture inputs if using more than one source or an external
trigger.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 71
