Page #216 background image
Status and Events
3−18
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Table 3-4 shows the error messages generated by improper
command syntax. Check that the command is properly formed and
that it follows the rules in the Command Syntax section starting on
page 2-1.
Table 3−4: Command error messages – CME bit 5
Code Message
100 Command error
102 Syntax error
103 Invalid separator
104 Data type error
105 GET not allowed
108 Parameter not allowed
110 Command header error
111 Header separator error
112 Program mnemonic too long
113 Undefined header
161 Invalid block data (indefinite length blocks are not allowed over
the RS−232)
Table 3-5 lists the errors that are detected during execution of a
command. In these error messages, you should read macro as
alias.
Table 3−5: Execution error messages – EXE bit 4
Code Message
200 Execution error
201 Invalid while in local
210 Trigger error
