Tektronix TDS1002 Programmer's Manual

Status and Events
3−20
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Table 3−5: Execution error messages – EXE bit 4 (Cont.)
Code Message
2210 Measurement error, No Mid Ref crossing, second waveform
2211 Measurement error, No backwards Mid Ref crossing
2212 Measurement error, No negative crossing
2213 Measurement error, No positive crossing
2214 Measurement error, No crossing
2215 Measurement error, No crossing, second waveform
2216 Measurement error, No crossing, target waveform
2217 Measurement error, Constant waveform
2218 Measurement error, Unused
2219 Measurement error, No valid edge: No arm sample
2220 Measurement error, No valid edge: No arm cross
2221 Measurement error, No valid edge: No trigger cross
2222 Measurement error, No valid edge: No second cross
2223 Measurement error, waveform mismatch
2224 Measurement error, WAIT calculating
2225 Measurement error, No waveform to measure
2226 Null Waveform
2227 Positive and Negative Clipping
2228 Measurement error, Positive Clipping
2229 Measurement error, Negative Clipping
2230 Measurement error, High Ref < Low Ref
2235 Math error, Invalid math description
2241 Waveform request is invalid
2242 Data start > record length

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
