Tektronix TDS1002 Programmer's Manual

Command Descriptions
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−39
<NR1> is the number of waveform acquisitions. Correct values are 4,
16, 64, and 128.
ACQuire:NUMAVg 16
specifies that an averaged waveform will show the result of
combining 16 separately acquired waveforms.
ACQuire:NUMAVg?
might return 64, indicating that there are 64 acquisitions specified
for averaging.
ACQuire:STATE
Starts or stops oscilloscope acquisitions. This command is the
equivalent of pressing the front-panel RUN/STOP button. If
ACQuire:STOPAfter is set to SEQuence, other signal events may
also stop acquisition.
NOTE. The best way to determine when a single sequence acquisition
is complete is to use *OPC? rather than ACQuire:STATE?. For more
information on the *OPC? command, refer to page 2-121.
Acquisition
ACQuire:STATE { OFF | ON | RUN | STOP | <NR1> }
ACQuire:STATE?
OFF | STOP | <NR1> = 0 stops acquisitions.
Arguments
Examples
Group
Syntax
Arguments

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
