Command Descriptions
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−43
AUTOSet:SIGNAL? (Query Only)
NOTE. You can use this command ONLY with the TDS1000 and
TDS2000 series.
Returns the type of signal discovered by the most recent execution of
Autoset.
Miscellaneous
AUTOSet:SIGNAL?
{ LEVEL | SINE | SQUARE | VIDPAL | VIDNTSC | OTHER |
NONE }
LEVEL
The oscilloscope discovered a DC level.
SINE
The oscilloscope discovered a sine-like waveform.
SQUARE
The oscilloscope discovered a square-like waveform.
VIDPAL
The oscilloscope discovered a PAL or SECAM standard video
signal.
VIDNTSC
The oscilloscope discovered an NTSC standard video signal.
OTHER
The oscilloscope was unable to classify the signal.
NONE
The AUTOSET menu is not displayed.
Group
Syntax
Returns
