Tektronix TDS1002 Programmer's Manual

Command Descriptions
2−60
TDS200/1000/2000 Series Oscilloscope Programmer Manual
NOTE . If Trigger View is active, the query form returns 9.9E37 and
generates event 221 (Settings conflict).
Cursor
CURSor:HBArs:POSITION<x> <NR3>
CURSor:HBArs:POSITION<x>?
<x> specifies which cursor position, and has the value of 1 or 2.
<NR3> specifies the horizontal bar cursor position, relative to ground
(in volts when the units are volts), relative to the center of the screen
(in divs when units are divisions), or relative to 1 V RMS (in
decibels when the source is an FFT math waveform), for the
waveform specified by the CURSor:SELect:SOUrce command.
The cursor position is limited to the graticule whenever an attempt is
made to move it outside the graticule.
NOTE . The source always determines the measurement units.
CURSor:HBArs:POSITION1 25.0E–3
positions one of the horizontal cursors at 25.0 mV (assuming the
vertical units are volts).
CURSor:HBArs:POSITION2?
might return –6.40E–2, indicating that the second horizontal bar
cursor is at –64.0 mV (assuming the vertical units are volts).
Group
Syntax
Arguments
Examples

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
