Tektronix TDS1002 User Manual

TDS2CMA Communications Module
132
TDS1000/2000-Series Digital Oscilloscope User Manual
Option Settings Comments
Layout Portrait, Landscape Printer output orientation
Format Thinkjet, Deskjet, Laser Jet,
Bubble Jet, Epson, BMP, PCX,
TIFF, RLE, EPSIMAGE,
DPU411, DPU412, DPU3445
Type of device connected to
the communications port
Port Centronics, RS-232, GPIB C ommunications port used to
connect the oscilloscope to a
printer or computer
Ink Saver* On, Off On prints the screen data on a
white background
Abort
Printing
Stops sending screen data to
theprinter
*
Only for TDS2000-series oscilloscopes.
NOTE. If you use the R S-232 or GPIB port, you also need to set up
the parameters for the port appropriately for your printer.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
