Appendix A: Specificati ons
152
TDS1000/2000-Series Digital Oscilloscope User Manual
Oscilloscope Specifications (Cont.)
Inputs
Input Coupling DC, AC, or GND
Input Impedance, DC
Coupled
1MΩ ±2% in parallel with 20 pF ±3pF
P2200 Probe
Attenuation
1X, 10X
Supported Probe
Attenuation Factors
1X, 10X, 100X, 1000X
Maximum Voltage
B
S
i
l
d
Overvoltage Category Maximum Voltage
g
Between Signal and
C
o
m
m
o
n
a
t
i
n
p
u
t
B
N
C
CAT I and CAT II 300 V
RMS
, Installation Category II
C
o
m
m
o
n
a
t
i
n
p
u
t
B
N
C
CAT III 150 V
RMS
Installation Category II; derate at 20 dB/decade above 100 kHz
to 13 V peak AC at 3 MHz* and above. For non-sinusoidal
waveforms, peak value must be less than 450 V. Excursion
above 300 V should be less than 100 ms duration. RMS signal
level including any DC component removed through AC coupling
must be limited to 300 V. If these values are exceeded, damage
to the instrument may result. Refer to the Overvoltage Category
description on page 164.
* Bandwidth reduced to 6 MHz with a 1X probe.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
