Appendix A: Specificati ons
162
TDS1000/2000-Series Digital Oscilloscope User Manual
Oscilloscope General Specifications (Cont.)
Environmental
Temperature Operating 32° F - 122° F
(0° Cto+50° C)
Nonoperating -- 4 0 ° F - 159.8° F
(--40° Cto+71° C)
Cooling Method Convection
Humidity +104° F or below
(+40° C or below)
≤ 90% relative humidity
106° F - 122° F
(+41° Cto+50° C)
≤ 60% relative humidity
Altitude Operating and Nonoperating 3,000 m (10,000 ft)
Random Vibration Operating 0.31 g
RMS
from 5 Hz to 500 Hz,
10 minutes on each axis
Nonoperating 2.46 g
RMS
from 5 Hz to 500 Hz,
10 minutes on each axis
Mechanical Shock Operating 50 g, 11 ms, half sine
Mechanical
Size Height 151.4 mm (5.96 in.)
Width 323.8 mm (12.75 in.)
Depth 124.5 mm (4.90 in.)
Weight (approximate) When packaged for domestic
shipment
3.6kg(8.0lbs)

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
