Appendix E: Performance Verification
TDS3000 Series User Manual
E–15
20. Set the output amplitude of the leveled sine wave generator so the
peak-to-peak measurement is approximately 500 mV.
21. Push the SET TO 50% button. Adjust the trigger LEVEL as
necessary and then verify that triggering is stable.
22. Push the trigger MENU button.
23. Push the Slope screen button and select the \ (falling) slope.
24. Push the SET TO 50% button. Adjust the trigger LEVEL as
necessary and then verify that triggering is stable.
25. Push the Slope screen button and select the / (rising) slope.
26. Push the waveform off
button.
27. Repeat steps 11 through 26 for each channel of the oscilloscope
(not including the external trigger input on some models).
