QuickMenu
TDS3000 Series User Manual
3–39
QuickMenu
Push the QUICKMENU button to see a set of frequently used menu
functions on the display. QuickMenus simplify oscilloscope
operation and can increase your productivity.
Scope is a standard QuickMenu for general purpose oscilloscope use.
Some optional application modules also include a custom QuickMe-
nu display. See page 1–28 for an example of the Scope QuickMenu.
Key Points
Using the QuickMenus. To use a QuickMenu, push the screen button
that corresponds to the control you need to set. Push the screen
button repeatedly to choose one of the settings. The small arrow icon
indicates that there are additional settings available that are not
shown.
You can use most of the front-panel controls at the same time you
are using a QuickMenu. For example, if you push a channel button
to select a different channel, the QuickMenu changes to show
information about that channel.
Using Other Menus. You can still use the regular menus. For example,
if you push the MEASURE button, you can set up and take
automatic waveform measurements in the usual way. If you return to
the QuickMenu, the measurement is still displayed on the screen.
Selecting Between QuickMenus. You may have optional application
modules installed that also have QuickMenu displays. To select the
QuickMenu you want to use, push the MENU screen button. This
menu item is shown only if application modules that contain a
QuickMenu are installed.
