Getting Started
1–22
TDS3000 Series User Manual
WAVEFORM
INTENSITY
SCALE SCALE
POSITION POSITION LEVEL
VERTICAL HORIZONTAL TRIGGER ACQUIRE
987
7. Vertical MENU. Adjusts the scale, position, and offset of
waveforms. Sets the input parameters.
8. Trigger MENU. Adjusts the trigger functions.
9. Acquire MENU. Sets the acquisition modes and horizontal
resolution, and resets the delay time.
