Getting Started
TDS3000 Series User Manual
1–27
5. Waveform record icon shows the trigger location relative to the
waveform record. The line color corresponds to the selected
waveform color.
6. Trigger status readout show trigger status.
7. Trigger level icon shows the trigger level on the waveform. The
icon color corresponds to the trigger source channel color.
8. Cursor and measurement readouts show results and messages.
9. Trigger readouts show the trigger sources, slopes, and levels, and
position.
10. Readout shows the delay setting or the trigger location within the
record.
11. Horizontal readout shows the main or zoom time/division.
12. Auxiliary waveform readouts show the vertical and horizontal
scale factors of the math or reference waveforms.
13. Channel readouts show the channel scale factor, coupling, input
resistance, bandwidth limit, and invert status.
14 15
14. Triangle icon with the battery icon indicates a battery is installed
and battery power is in use. The battery icon shows the
approximate charge level of the battery. See page 1–11 for
important safety information.
15. Power-plug icon with the battery icon indicates a battery is
installed but line power is in use. The battery may be charging.
The battery icon shows the approximate charge level.
