Tektronix TDS5000B Series Specification And Performance Verification Technical Reference

Specifications
1-6
TDS5000B Series Specifications and Performance Verification
Specification Tables
Table 1- 2: Channel input and vertical specifications
Characteri sti c Description
Input coupling AC, DC, and GND
Input channels
TDS5034B, TDS5054B, TDS5054BE,
TDS5104B
Four identical channels
TDS5032B, TDS5052B Two identical channels
Input impedance selection 50 Ω or 1 MΩ.
TDS5104B bandwidth limited to 500 MHz, 1 MΩ selected
Input impedance, DC coupled Product Limits
50 Ω,typical TDS5032B, TDS5052B,
TDS5034B, TDS5054B,
TDS5054BE
±1.0%
TDS5104B ±2.5%
VSWR TDS5032B, TDS5034B ≤1.6:1 typical from DC to 350 MHz
TDS5052B, TDS5054B,
TDS5054BE
≤1.6:1 typical from DC to 500 MHz
TDS5104B ≤1.5:1 typical from DC to 1 GHz
1MΩ TDS5032B, TDS5052B,
TDS5034B, TDS5054B,
TDS5054BE
±1.0% in parallel with 15.5 pF ±2pF
TDS5104B ±1.0% in parallel with 18 pF ±2pF
Maximum voltage at input BNC AC, DC, or GND coupled
1MΩ 150 V
RMS
CAT I, and ≤400 peak
For steady state sinusoidal waveforms, derate at 20 dB/decade above 200
kHz to 9 V
RMS
at ≥3MHz
50 Ω TDS5032B, TDS5052B,
TDS5034B, TDS5054B,
TDS5054BE
5V
RMS
with peaks less than ±30 V
TDS5104B <1 Vrms for settings below 100mV/div
<5 Vrms for 100 mV/div settings and above
n Differential delay, DC 50 Ω input ≤100 ps between any two channels with DC input coupling and the same
V/div scale settings at or above 10 mV/div
Deskew range, typical ±75.0 ns
n Channel-to-channel crosstalk ≥100:1 at ≤100 MHz
