Performance Tests
2-30
TDS5000B Series Specifications and Performance Verification
H Press the front-panel Vertical button that corresponds to the channel
that you are to confirm.
H Move the leveling output of the sine wave generator to the channel
that you selected.
b. Match the trigger source to the channel selected:
H Press the Trigger SOURCE button until the source that corresponds
to the channel that you are to confirm is on.
c. Set its input impedance:
H From the toolbar, click the VERT button and select the tab for the
channel that you are to confirm. Click the Termination 50 Ω button.
d. Set the vertical scale: Set the vertical SCALE that corresponds to the
channel that you are to confirm to one of the settings listed in Table 2--3
not yet checked. (Start with the 100 mV setting.)
e. Set the triggering coupling:
H Click the Coupling DC button.
Table 2- 3: Analog bandwidth
Test frequency
Vertical
scale
Reference
amplitude
(6 division)
Horizontal
scale
TDS5032B
TDS5034B
TDS5052B
TDS5054B
TDS5054BE
TDS5104B
- 3 db Limits
1mV 6mV 1ns 150 MHz 175 MHz 175 MHz ≥4.24 mV
2mV 12 mV 1ns 250 MHz 300 MHz 1GHz ≥8.48 mV
5mV 30 mV 1ns 350 MHz 500 MHz 1GHz ≥21.2 mV
10 mV 60 mV 1ns 350 MHz 500 MHz 1GHz ≥42.4 mV
20 mV 120 mV 1ns 350 MHz 500 MHz 1GHz ≥84.8 mV
50 mV 300 mV 1ns 350 MHz 500 MHz 1GHz ≥212 mV
100 mV 600 mV 1ns 350 MHz 500 MHz 1GHz ≥424 mV
200 mV 1.2 V 1ns 350 MHz 500 MHz 1GHz ≥848 mV
500 mV 3V
1
1ns 350 MHz 500 MHz 1GHz ≥2.12 V
1
1V 6V
1
1ns 350 MHz 500 MHz 1GHz ≥4.24 V
1
1
If your generator cannot output 6 divisions of amplitude, determine its maximum output at the Test
frequency, and use this for the reference amplitude. The -3 db limit can be calculated as: 0.707 ×
reference amplitude.
