Specifications
TDS5000B Series Specifications and Performance Verification
1-23
Table 1- 11: Certifications and compliances
Category Standards or description
EC Declaration of Conformity --
EMC
Meets intent of Directive 89/336/EEC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as l isted in the Official Journal of the European Union:
EN 61326 Emissions
1, 3, 4
Class A Radiated and Conducted Emissions
EN 61326 Immunity
1, 4
IEC 61000-4-2 Electrostatic Discharge Immunity
±4 kV contact discharge, ±8 kV air discharge
IEC 61000-4-3 RF field immunity
3V/m,80MHzto1GHz,
80% amplitude modulated with a 1 kHz sinewave
2
IEC 61000-4-4 Electrical Fast Transient/ Burst Immunity
1 kV on AC mains, 500 V on I/O
IEC 61000-4-5 AC Surge Immunity
500 V differential mode, 1 kV common m ode
IEC 61000-4-6 RF Conducted Immunity
3 V, 150 kHz to 80 MHz, amplitude modulated wit h a
1 kHz sinewave
2
IEC 61000-4-11 AC Mains Voltage Dips and Interruption Immunity
100% reduction for one cycle
EN 61000-3-2 Power Harmonic Current Emissions
EN 61000-3-3 Voltage Changes, Fluctuations, and Flicker
1
Use low-EMI shielded interconnect cables, equivalent to the following Tektronix cables:
GPIB cable: 012-0991-01, 012-0991-02, or 012-0991-03.
RS-232 cable: 012-1213-00 or CA part number 0294-9.
Centronics Cable: 012-1214-00 or LCOM part number CTL3VGAMM-5 VGA Cable.
2
Under theses conditions, the specif ications are amended as follows:
1 mV/division to 1 V/division: ≤0. 2 division waveform di s placement or ≤0.4 division increase
in peak-to-peak noise.
3
Radiated emissions may exceed the levels speci fied in EN 61326 when this oscilloscope is
connected to a test object.
4
Tested in accordance with EN 61326 Annex D.
FCC Radiated and conducted emi ssions do not exceed the levels specified in FCC47 CFR, Part 15,
Subpart B, for Class A equipment.
