Specifications
1-14
TDS5000B Series Specifications and Performance Verification
Table 1- 3: Horizontal and acquisition system specifications (Cont.)
Characteri sti c Description
n Delta time measurement
accuracy
For a single channel, with signal amplitude > 5 div,
reference level set at 50%, interpolation set to sin(x)/x,
volts/division set to ≥ 5 mV/div, with (displayed
risetime)/(sample interval) ratio between 1.4 and 4, where
sample interval = 1/(real-time sample rate)
Conditions Accuracy
Single shot signal, Sample,
or Hi Res acquisition mode,
Full bandwidth
± (15 ppm × | reading | +
0.3 sample intervals)
Average acquisition mode,
≥100 averages, Full band-
width
± (15 ppm × | reading | +
20 ps)
Table 1- 4: Trigger specifications
Characteri sti c Description
Auxiliary trigger input resistance,
typical
≥1.5 kΩ
Maximum trigger input voltage,
typical
±20 V (DC or peak AC)
n Edge trigger sensitivity, Main
and Delayed trigger
Trigger Source Sensitivity
TDS5032B, TDS5034B Any channel, DC coupled 0.35 div from DC to
50 MHz, increasing to 1 div
at 350 MHz
Auxiliary input 400 m V from DC to
50 MHz, increasing to
750 mV at 100 MH z
TDS5052B, TDS5054B,
TDS5054BE
Any channel, DC coupled 0.35 div from DC to
50 MHz, increasing to 1 div
at 500 MHz
Auxiliary input 400 m V from DC to
50 MHz, increasing to
750 mV at 100 MH z
TDS5104B Any channel, DC coupled 0.35 div from DC to
50 MHz, increasing to 1 div
at 1 GHz
Auxiliary input 400 m V from DC to
50 MHz, increasing to
750 mV at 100 MH z
