Tektronix TDS5000B Series

Performance Tests
2-20
TDS5000B Series Specifications and Performance Verification
TDS5000B Series Test Record
Photocopy this table and use it to record the performance test results for your
TDS5000B Series Oscilloscope.
TDS 5000B Series Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS5000B Series performance test Minimum Incoming Outgoing Maximum
DC voltage measurement accuracy (averaged)
CH1 5 mV Vert scale setting,
--5 Div position setting, +1 V off set
+ 1.0353 V __________ __________ + 1.0447 V
CH1 5 mV Vert scale setting,
+5 Div position setting, --1 V offset
-- 1.0447 V __________ __________ -- 1.0353 V
CH1 200 mV Vert scale setting,
--5 Div position setting, +10 V off set
+ 11.4989 V __________ __________ + 11.7011 V
CH1 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.7011 V __________ __________ -- 11.4989 V
CH1 1.01 V Vert scale setting,
--5 Div position setting, +10 V off set
+ 17.602 V __________ __________ + 18.398 V
CH1 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.398 V __________ __________ -- 17.602 V
CH2 5 mV Vert scale setting,
--5 Div position setting, +1 V off set
+ 1.0353 V __________ __________ + 1.0447 V
CH2 5 mV Vert scale setting,
+5 Div position setting, --1 V offset
-- 1.0447 V __________ __________ -- 1.0353 V
CH2 200 mV Vert scale setting,
--5 Div position setting, +10 V off set
+ 11.4989 V __________ __________ + 11.7011 V
CH2 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.7011 V __________ __________ -- 11.4989 V
CH2 1.01 V Vert scale setting,
--5 Div position setting, +10 V off set
+ 17.602 V __________ __________ + 18.398 V
CH2 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.398 V __________ __________ -- 17.602 V
CH3 5 mV Vert scale setting,
--5 Div position setting, +1 V off set
+ 1.0353 V __________ __________ + 1.0447 V
CH3 5 mV Vert scale setting,
+5 Div position setting, --1 V offset
-- 1.0447 V __________ __________ -- 1.0353 V
CH3 200 mV Vert scale setting,
--5 Div position setting, +10 V off set
+ 11.4989 V __________ __________ + 11.7011 V
