Tektronix TDS5000B Series

Performance Tests
TDS5000B Series Specifications and Performance Verification
2-21
TDS 5000B Series Test Record (cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS5000B Series performance test MaximumOutgoingIncomingMinimum
CH3 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.7011 V __________ __________ -- 11.4989 V
CH3 1.01 V Vert scale setting,
--5 Div position setting, +10 V off set
+ 17.602 V __________ __________ + 18.398 V
CH3 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.398 V __________ __________ -- 17.602 V
CH4 5 mV Vert scale setting,
--5 Div position setting, +1 V off set
+ 1.0353 V __________ __________ + 1.0447 V
CH4 5 mV Vert scale setting,
+5 Div position setting, --1 V offset
-- 1.0447 V __________ __________ -- 1.0353 V
CH4 200 mV Vert scale setting,
--5 Div position setting, +10 V off set
+ 11.4989 V __________ __________ + 11.7011 V
CH4 200 mV Vert scale setting,
+5 Div position setting, --10 V offset
-- 11.7011 V __________ __________ -- 11.4989 V
CH4 1.01 V Vert scale setting,
--5 Div position setting, +10 V off set
+ 17.602 V __________ __________ + 18.398 V
CH4 1.01 V Vert scale setting,
+5 Div position setting, --10 V offset
-- 18.398 V __________ __________ -- 17.602 V
Analog bandwidth
CH1 100 mV 424 mV __________ __________ N/A
CH2 100 mV 424 mV __________ __________ N/A
CH3 100 mV 424 mV __________ __________ N/A
CH4 100 mV 424 mV __________ __________ N/A
Delay between channels N/A __________ __________ 100 ps
