Performance Tests
2-54
TDS5000B Series Specifications and Performance Verification
f. Repeat step 1, substep c and step 3, substep b only, to check the full
bandwidth of the Aux Trigger source. Set the frequency to 100 MHz.
NOTE. You just checked the trigger sensitivity. If desired, you can repeat steps 1
through 4d for the other channels (CH 2, and, if equipped, CH 3 and CH 4).
5. Disconnect the hookup: Disconnect the cables from AUX IN and from the
channel last tested.
