Tektronix THDP0100 User Manual

Performance Ver
ification
Test Record
Photocopy this test record for recording the results of the performance verification procedures.
Table 13: THDP & TMDP Series probes test record
Probe Model:
Probe Serial Number:
Temperature:
Certificate Number:
RH%:
Technician:
Date of Calibration:
Probe test Range Minimum Incoming Outgoing Maximum
Gain accuracy
THDP0100 600 V 735 mV 765 mV
6000 V 73.5 mV 76.5 mV
THDP0200 150 V 490 mV 510 mV
1500 V 147 mV 153 mV
TMDP0200 75 V 784 mV 816 mV
750 V 235.2 mV 244.8 mV
Rise time
THDP0100 600 V
—
3.6 ns
6000 V
—
3.6 ns
THDP0200 150 V
—
2.4 ns
1500 V
—
2.0 ns
TMDP0200 75 V
—
2.4 ns
750 V
—
2.0 ns
THDP0100/0200 & TMDP 0200 High Voltage Differential P robes Instruction Manual 38
